LED Downlight Round Stable D80 3W
LED Downlight Round Stable D80mm 3W Simple Installation 120° Beam Angle.
Notes
LED Downlight Round Stable D80mm 3W
Simple Installation 120° Beam Angle.
- Ideal for Offices, Home appliances, Corridors, Venues, Stores, Shopping Centers, Car Lifts.
- Easy installation.
- Energy saving up to 80%.
- Diffused light 120 °
- No IR and UV radiation.
- Mercury free.
- Rated Lifetime: 50.000 hrs
- Diameter LED PCB: 50 mm
| Mechanical | |
|---|---|
| Cut Hole | Ø 65 mm |
| Dimensions | Ø 80 mm |
| Case Color | Black, Chrome, Satin, White |
| Electrical | |
| Rated Power Consumption | 2.7 W |
| Operating Voltage | 12V, 210...240V, 24V, 48V |
| Operating Frequency | 50–60 Hz |
| Optical | |
| Rated Efficacy | 165 lm/W |
| Beam Angle | 120° |
| Number of LEDs | 48 |
| Kelvin | 2700K, 3000K, 4000K, 6000K |
| Rated luminous flux (6000K) | 495lm |
| Other | |
| Mount Type | Flush Mount |
| Case Material | Aluminium |
| Lamp Equivalent | 50W |
| CRI | >90 |
| Power Factor | 0.99 |
Documents
- Spot Datasheet Φ50 12-
230V Language: MultilingualFormat: PDFSize: 165 KB
- Spot Datasheet Φ50 12-
230V Language: ENFormat: PDFSize: 184 KB
| Document | Language | Format | Size |
|---|---|---|---|
| Spot Datasheet Φ50 12- | Multilingual | 165 KB | |
| Spot Datasheet Φ50 12- | EN | 184 KB |
