Redphone Ultra
The all-new Redphone ULTRA Autodialer features an exceptionally slim design, measuring only 17mm in thickness, to accommodate the latest cutting-edge hardware specifications. It fully complies with the most current EN 81-20/28/72 directives, ensuring top-tier safety standards. Supporting up to 2 voice terminals and an additional extension voice terminal for cabin COP, this Autodialer is incredibly versatile, capable of seamlessly fitting into almost any installation and accommodating various specialized requirements our customers may have. The innovative design not only ensures excellent two-way communication quality but also offers an intuitive and straightforward programming menu, setting it apart in the market without sacrificing the complexity and programmable capabilities that the best Autodialer should possess. With the most extensive and advanced list of user programming codes available on the market, Redphone ULTRA can be confidently installed in even the most challenging and unique hardware environments and Telephone Center Services.
| Model | INTD0902 |
|---|---|
| Power Supply | 12V/24V |
| Rated Power Consumption | 150mA Normal / 300mA Peak |
| Recorded messages Languages (ROM) | English, Greek, France, German |
| Recorded messages Languages(microSD) | Can be any language according customer needs |
| Inputs | 2 Emergency Call switches |
| Outputs | 2 Pictograms Power outputs |
| Connections | 3-Wire Intercom / Firecom BUS |
| Installation Place | Above the Car Lift, Behind COP |
| Extra Functions and Special Features | Remotely programable via incoming Telephone Call. |
| Case Material | Plastic |
| Battery | No |
| Mount Type | Flush Mount |
| Dimensions (External) | 140 x 95 x 17 mm (H x W x D) |
| Weight | 120g |
